Blue Carbon · Smart Power Station

Smart Power Station 220V / 18 kW / 45 kWh

All-in-one 220V residential and small commercial energy storage with 51.2 V / 900 Ah battery and WiFi monitoring.

Inverter power

18 kW

Battery energy

45 kWh

Battery

51.2 V / 900 Ah

Max parallel

3 units (54 kW)

Model: Smart Power Station 220V/18kW (45kWh)

Request a Quote Download Datasheet (PDF)

Product Overview

The Smart Power Station 220V/18kW (45kWh) is an all-in-one energy storage system combining an inverter and a LiFePO4 battery. The manufacturer describes it for residential and small commercial use with stable power supply and flexible energy management.

Battery nominal capacity is 51.2 V / 900 Ah (45 kWh), and the inverter provides up to 18 kW. It supports solar PV input and 220V AC grid connection, with up to 3 units in parallel for 220V / 54 kW. Built-in WiFi supports monitoring and remote control through a local interface or a web platform.

The datasheet lists the 220V range under a 220V single-phase solution, and the input wiring is L+N+PE. We make no claim of compatibility with any particular Iraqi electrical installation; please confirm with a qualified electrician.

Technical Specifications

Specifications are taken from the manufacturer's product page and datasheet. Fields that the manufacturer does not publish are stated as such rather than estimated.

Battery nominal capacity

900 Ah

Battery nominal voltage

51.2 V

Battery energy

45 kWh

Battery chemistry

LiFePO4

Cycle life

Over 6000 cycles (manufacturer)

Inverter max power

18 kW

AC output voltage

208 / 220 / 230 / 240 VAC

Electrical configuration

220V single-phase solution (L+N+PE), per the datasheet

Frequency

50/60 Hz ±0.1%

Switch time

10 ms (normal mode) / 10 ms (UPS mode)

Max parallel

3 groups (54 kW)

AC input

208/220/230/240 VAC; L+N+PE

Solar charger

MPPT

Max PV input

18 A / 6000 W × 3

MPPT range (per unit)

120–450 VDC

Monitoring

Built-in WiFi; local interface or web platform

Warranty, dimensions, weight, operating temperature, certifications

Not specified in the available manufacturer documentation.

Product Features

All-in-one design

Inverter and LiFePO4 battery in one unit, reducing wiring complexity.

Parallel output up to 54 kW

Up to 3 units in parallel for 220V / 54 kW.

Multi-source compatibility

Solar PV input and 220V AC grid connection.

WiFi monitoring

Real-time data collection, monitoring and remote control.

Intelligent energy optimization

Stores energy off-peak and releases it at peak demand.

LiFePO4 battery

Over 6000 cycles.

Applications

Residential use, villas, homestays and small shops, as described in the datasheet.
Small commercial energy needs and rural energy backup.
Lighting, air conditioning and water-heating loads, within the system's rated capacity.

Compatibility with a specific installation depends on its electrical configuration and the manufacturer's documentation. Confirm with a qualified electrician before purchase.
